AI Should Explain Engineering Validation, Not Invent It
May 2026 · Damir Andrijanic · 9 min read
The high-stakes validation trap
Most AI applications in 2026 focus on generation: writing code, drafting emails, or producing generic text. While impressive, this generative model falls apart in high-precision engineering workflows like BIM (Building Information Modeling). In CAD/BIM validation, if a compliance reviewer asks if a structural room meets safety codes, a 'hallucinated' or plausible-sounding answer is worse than no answer.
BIM models represent complex spatial elements—levels, rooms, doors, and fire boundaries. Traditional compliance checks are done via strict, deterministic formulas. The moment we inject standard generative AI into this loop, we risk hallucinating metrics, mapping wrong relations, or declaring compliance where it fails. Yet, simple deterministic error codes are cryptic and hard for human architects to review. How do we get the best of both worlds?
Constrained Explanation: The ADAS Spec Validator
I built the ADAS Spec Validator to prove a fundamental design pattern: AI should explain engineering validation, never invent it.
The system splits validation into two isolated layers. First, a client-side deterministic rule engine, built with TypeScript and Zod, parses Revit/CAD JSON models and evaluates strict compliance requirements (e.g. minimum room areas, fire door connectivity, path distances). It emits a strict evidence contract. Second, an AI explanation router (Gemini 2.5 Flash / OpenAI) receives ONLY this verified evidence. It is strictly forbidden by an ADAS System Prompt from inferring missing facts or inventing data, focusing solely on explaining the exact reasoning in natural language.
System Architecture & Data Flow
The data flow guarantees complete separation of the AI explainer from raw model geometry. Mathematical calculations and boundaries are executed deterministically.
Core engineering stack
BIM Extractor Boundary
A C# .NET console application modeling the Revit API boundary, extracting levels, rooms, and door relations into a sanitized JSON contract.
Type-Safe Validation
TypeScript and Zod schemas to ingest, validate, and sanitize the normalized CAD/BIM data model, preventing garbage-in-garbage-out errors.
Deterministic Rules
Strict TypeScript rule engines evaluating custom compliance rules (like MinimumRoomAreaRule, MinimumDoorWidthForRoomTypeRule) and producing detailed validation evidence.
AI Explanation Engine
Google Gemini 2.5 Flash API as a fast, high-context explanation engine, with automated provider fallbacks to OpenAI's GPT-4o-mini.
Reliability Testing
Vitest suite verifying type safety, rule engine correctness, fallback mechanics, and strict prompt compliance boundaries.
Visual UI Interface
Next.js 15 (App Router) and Tailwind CSS displaying real-time validation passes, violations, and the natural language explanation panel.
Key architectural breakthroughs
1) Eliminating LLM Hallucinations in Compliance
The Risk: When an LLM is directly asked to read a raw BIM JSON model and assess safety rules, it frequently confuses IDs, fabricates wall thicknesses, and miscalculates simple geometry.
The Solution: I isolated the AI entirely from the raw calculation. The TypeScript rule engine executes the mathematics, compiling a structured array of 'evidence' (observed value, expected threshold, target IDs). The AI is presented with this evidence and a system prompt that mandates returning 'I cannot determine that from the available model evidence' if any fact is missing.
2) Handling Missing and Unknown States Gracefully
The Risk: Real-world CAD exports are incomplete. Missing areas, unmapped doors, or missing level tags usually cause standard rules to crash or AI models to invent missing data.
The Solution: I implemented a three-state validation model: PASS, FAIL, and UNKNOWN. If a room has no area parameter, the rule engine marks it UNKNOWN and outputs precise evidence describing the missing property. The AI respects this state, explaining exactly why the verification is stalled rather than trying to guess it.
3) C# Revit Extraction Normalization
The Risk: Revit objects contain thousands of raw parameters, cyclic structural dependencies, and internal coordinates that are too noisy and heavy for web apps or prompt contexts.
The Solution: I built a C# console extractor that resolves these heavy dependencies using a Revit-inspired DTO structure. It flattens spatial elements into standard Levels, Rooms, and Doors JSON, representing the exact data contract between desktop CAD and web compliance engines.
The UX: Bringing Clarity to Complexity
Human reviewers don't want black boxes. The ADAS interface pairs clean status badges (PASS / FAIL / WARNING) with direct highlights of affected element IDs (e.g. rm-meet-01). The AI explanation acts as a smart, natural-language sidekick—brief, evidence-backed, and directly telling the architect which door parameter to fix in Revit.
Proven Results
By separating deterministic evaluation from prompt-based translation, the system achieves 100% mathematical precision while maintaining natural user interaction.
Validation Accuracy
100% Deterministic
AI Explanation Logic
Evidence-Grounded
This prototype shows that engineering-grade trust is achievable when we treat the AI as a communication interface rather than a calculation engine.
Takeaway
Don't let AI calculate what a 10-line math formula can solve perfectly. Use code for math, logic, and safety guardrails. Use AI for context, translation, and user-centric explanation. That is the architecture of trust.
